ESP32 MCP Server

A Model Context Protocol (MCP) server running on ESP32 (and Nordic nRF52840 in sensor-only mode), exposing real-world sensor data and bus protocols to AI assistants and automation tooling over WebSocket / JSON-RPC 2.0.

Connect an AI agent directly to your hardware: query I2C sensors, parse NMEA 0183 GPS/marine data, decode NMEA 2000 and OBD-II CAN frames, replay bus history — all through a standard MCP interface.

architecture

---

Features

Capability	Details
MCP Protocol	JSON-RPC 2.0 over WebSocket, resource discovery & subscriptions
I2C Sensors	Auto-scan + drivers for BME280, MPU6050, ADS1115, SHT31, BH1750, INA219
NMEA 0183	GGA, RMC, VTG, GSV, MWV, DBT, DPT, HDG, HDT with XOR checksum validation
NMEA 2000 / CAN	29-bit PGNs: position, heading, speed, depth, wind, attitude, water temp
OBD-II / CAN	Standard 11-bit OBD-II service 01/09 PID decoding (60+ PIDs)
Bus History	Persistent ring buffers for CAN, NMEA, NMEA 2000, OBD-II — queryable via MCP
Bus Readers	Time-bounded serial and CAN reads, raw or parsed mode, JSON output
WiFi	AP setup UI + STA mode; credentials stored in NVS
Discovery	mDNS (`_mcp._tcp`) + UDP capability broadcast
Metrics	Heap, uptime, RSSI, histogram stats with boot persistence
Multi-board	ESP32-S3, ESP32-C3, ESP32, Adafruit HUZZAH32, M5Stack, Nordic nRF52840-DK, Adafruit Feather nRF52840
Testing	Native unit tests (Unity), mock I2C / CAN / Serial / LittleFS

---

Supported Boards

ESP32 Boards — Full MCP Server (WiFi + WebSocket + CAN)

Board	PlatformIO env	MCU	Flash	RAM	WiFi	BLE	CAN	RGB LED
ESP32-S3-DevKitC-1	`esp32-s3-devkitc-1`	Xtensa LX7 × 2 @ 240 MHz	8 MB	512 KB + 8 MB PSRAM	✓	5.0	✓	GPIO48
ESP32-DevKitC V4	`esp32-devkitc`	Xtensa LX6 × 2 @ 240 MHz	4 MB	520 KB	✓	4.2	✓	—
ESP32-C3-DevKitM-1	`esp32-c3-devkitm-1`	RISC-V @ 160 MHz	4 MB	400 KB	✓	5.0	✓	GPIO8
Adafruit HUZZAH32	`adafruit-huzzah32`	Xtensa LX6 × 2 @ 240 MHz	4 MB	520 KB	✓	4.2	✓	—
M5Stack Core ESP32	`m5stack-core`	Xtensa LX6 × 2 @ 240 MHz	16 MB	520 KB	✓	4.2	✗	—

nRF52840 Boards — Sensor Only (I2C + Serial, no WiFi)

Board	PlatformIO env	MCU	Flash	RAM	BLE
Nordic nRF52840-DK	`nrf52840-dk`	Cortex-M4F @ 64 MHz	1 MB	256 KB	5.0 + 802.15.4
Adafruit Feather nRF52840	`nrf52840-feather`	Cortex-M4F @ 64 MHz	1 MB	256 KB	5.0

nRF52840 targets run a separate main_nrf.cpp entry point: sensors + I2C + Serial output only. No WiFi, no MCP WebSocket, no LittleFS, no bus history. For full MCP-over-WiFi, bridge via an ESP32-C3 in AT-command mode connected to UART1.

Board Feature Matrix

Feature	ESP32-S3	ESP32 V4	ESP32-C3	HUZZAH32	M5Stack	nRF52840-DK	nRF52840-Feather
WiFi	✓	✓	✓	✓	✓	✗	✗
BLE	✓	✓	✓	✓	✓	✓	✓
CAN / TWAI	✓	✓	✓	✓	✗	✗	✗
I2C	✓	✓	✓	✓	✓	✓	✓
UART (ext)	✓	✓	✓	✓	✓	✓	✓
LittleFS	✓	✓	✓	✓	✓	✗	✗
MCP Server	✓	✓	✓	✓	✓	✗	✗
Bus History	✓	✓	✓	✓	✓	✗	✗
mDNS / UDP discovery	✓	✓	✓	✓	✓	✗	✗

---

Architecture

mermaid

flowchart TD
    Client[AI Agent / MCP Client] -->|WebSocket :9000 JSON-RPC 2.0| MCPServer

    subgraph ESP32
        MCPServer -->|resources/list| Resources
        MCPServer -->|sensors/i2c/scan| SensorMgr
        MCPServer -->|sensors/read| SensorMgr
        MCPServer -->|buses/serial/read| BusReader
        MCPServer -->|buses/can/read| BusReader
        MCPServer -->|bus/history/read| BusHistory
        MCPServer -->|bus/history/config/*| BusHistory

        SensorMgr -->|Wire I2C| I2CSensors[BME280 · MPU6050 · ADS1115\nSHT31 · BH1750 · INA219]
        BusReader -->|UART| NMEAParser[NMEA 0183 Parser]
        BusReader -->|CAN TWAI| CANParser[NMEA 2000 / OBD-II Parser]
        BusReader -->|feed| BusHistory[Bus History\nRing Buffers]
        BusHistory --> LittleFS

        NetworkMgr[Network Manager] --> WiFi
        NetworkMgr --> WebSetup[Setup UI :80]
        DiscoveryMgr[Discovery Manager] -->|mDNS + UDP| Network
        Metrics[Metrics System] --> LittleFS
        uLogger --> LittleFS
    end

    MCPServer --> Metrics
    MCPServer --> uLogger

---

Hardware

Pin Assignments (ESP32-S3-DevKitC-1)

GPIO	Function	Connected to
IO8	I2C SDA	All I2C sensors
IO9	I2C SCL	All I2C sensors
IO16	UART1 RX	GPS / chart plotter TX
IO17	UART1 TX	GPS / chart plotter RX (optional)
IO4	CAN RX	TJA1050 / SN65HVD230 CRXD
IO5	CAN TX	TJA1050 / SN65HVD230 CTXD

nRF52840-DK Pin Assignments

Pin	Function
P0.26 / D6	I2C SDA
P0.27 / D7	I2C SCL
P0.06 / TX	UART1 TX
P0.08 / RX	UART1 RX

Bill of Materials

#	Part	Purpose
1	ESP32-S3-DevKitC-1	Main MCU
1	BME280 breakout	Temperature / Humidity / Pressure
1	MPU6050 breakout	6-axis IMU (optional)
1	TJA1050 or SN65HVD230	CAN bus transceiver (optional)
1	GPS module (3.3 V UART)	NMEA 0183 position/time (optional)
2	4.7 kΩ resistors	I2C pull-ups
—	Breadboard + jumpers

ESP32-S3-DevKitC-1 Wiring

code

┌──────────────────────────────────────┐
                    │         ESP32-S3-DevKitC-1            │
                    │                                       │
             3V3 ───┤ 3V3                          GND ├─── GND
             GND ───┤ GND                          IO0 ├
                    │                                   │
  I2C SDA ── IO8 ───┤ IO8  ┌──────────┐       IO17 ├─── UART1 TX → GPS
  I2C SCL ── IO9 ───┤ IO9  │  ESP32   │       IO16 ├─── UART1 RX ← GPS
                    │ IO10 │    S3    │       IO15 ├
                    │ IO11 └──────────┘       IO14 ├
                    │ IO12                    IO13 ├
                    │ IO3                      IO4 ├─── CAN RX ← TJA1050
                    │ IO46                     IO5 ├─── CAN TX → TJA1050
                    │                               │
                    │    USB (flash / serial log)   │
                    └───────────────────────────────┘

I2C Sensor Wiring

All sensors share one bus. Add 4.7 kΩ pull-ups from SDA and SCL to 3V3.

code

ESP32-S3      BME280       MPU6050      ADS1115      INA219
─────────     ───────      ───────      ───────      ───────
IO8 (SDA)─────SDA──────────SDA──────────SDA──────────SDA
IO9 (SCL)─────SCL──────────SCL──────────SCL──────────SCL
3V3  ──────────VCC──────────VCC──────────VCC──────────VCC
GND  ──────────GND──────────GND──────────GND──────────GND
               SDO→GND      AD0→GND      ADDR→GND
               (0x76)       (0x68)       (0x48)       (0x40)

Other supported sensors (same bus wiring): SHT31 (0x44), BH1750 (0x23).

NMEA 0183 Wiring (GPS / Chart Plotter)

code

GPS / chart plotter              ESP32-S3
───────────────────              ────────
TX  (3.3 V TTL NMEA out) ─────── IO16 (UART1 RX)
RX  (optional NMEA in)   ─────── IO17 (UART1 TX)
GND                      ─────── GND
VCC (3.3 V)              ─────── 3V3

If the device outputs RS-232 levels, use a MAX3232 level shifter. Never connect RS-232 directly to ESP32 GPIO.

CAN Bus Wiring (NMEA 2000 / OBD-II)

code

TJA1050 / SN65HVD230             ESP32-S3
────────────────────             ────────
CTXD                  ─────────── IO5 (CAN TX)
CRXD                  ─────────── IO4 (CAN RX)
VCC (5 V for TJA1050) ─────────── VIN / external 5 V
GND                   ─────────── GND
CANH ──────────────── NMEA 2000 backbone / OBD-II CANH
CANL ──────────────── NMEA 2000 backbone / OBD-II CANL

NMEA 2000 runs at 250 kbps. OBD-II runs at 500 kbps. Set the baud rate in your CANBusReader configuration accordingly.

---

Software Prerequisites

PlatformIO Core CLI or the PlatformIO IDE plugin for VS Code
Python 3.8+
Git

bash

pip install platformio

---

Build & Flash

bash

# 1. Clone
git clone https://github.com/navado/ESP32MCPServer.git
cd ESP32MCPServer

# 2. Install library dependencies
pio pkg install

# 3. Upload web assets to LittleFS (optional but recommended)
pio run -t uploadfs -e esp32-s3-devkitc-1

# 4. Build firmware
pio run -e esp32-s3-devkitc-1

# 5. Flash
pio run -t upload -e esp32-s3-devkitc-1

# 6. Monitor
pio device monitor --baud 115200

nRF52840

bash

pio run -e nrf52840-dk
pio run -t upload -e nrf52840-dk

---

First Run

1. Power on the board. It broadcasts a WiFi AP: **ESP32_XXXXXX** (last 6 hex digits of the MAC address).

2. Connect to that AP and open **http://192.168.4.1**.

3. Enter your WiFi credentials and click Save.

4. The board joins your network and prints its IP address on the serial console.

5. Connect an MCP client to **ws://:9000**.

---

Web Dashboard

A browser-based dashboard is served from flash at **http:///app**.

Tab	What it does
Sensors	Scan I²C bus, display detected devices, read values, auto-refresh
Metrics	List all metrics, live values, sparkline history chart
Logs	Query and clear metric log entries
MCP Console	Interactive JSON-RPC console with preset requests and live message log

---

HTTP Endpoints (port 80)

Method	Path	Description
GET	`/`	WiFi setup page
POST	`/save`	Save WiFi credentials (`ssid`, `password` form params)
GET	`/status`	Network status JSON
WS	`/ws`	Real-time network status WebSocket
GET	`/app`	Browser dashboard
GET	`/bus-history`	Read bus history config JSON
POST	`/bus-history`	Update bus history config JSON

---

MCP API Reference (WebSocket port 9000)

All methods use JSON-RPC 2.0 over WebSocket.

Protocol

Method	Params	Description
`initialize`	—	Server info, protocol version, capabilities
`resources/list`	—	List registered MCP resources
`resources/read`	`uri`	Read a resource by URI
`resources/subscribe`	`uri`	Subscribe to push updates for a resource
`resources/unsubscribe`	`uri`	Cancel a subscription

Sensors

Method	Params	Description
`sensors/i2c/scan`	—	Scan I²C bus; auto-detect and initialise drivers
`sensors/read`	`sensorId?`	Read all channels of one sensor (omit ID to read all)

`sensors/i2c/scan`

json

{"jsonrpc":"2.0","method":"sensors/i2c/scan","id":1}

json

{
  "jsonrpc":"2.0","id":1,
  "result":{"devices":[
    {"address":118,"name":"BME280","supported":true,"parameters":["temperature","pressure","humidity"]},
    {"address":104,"name":"MPU6050","supported":true,"parameters":["accel_x","accel_y","accel_z","gyro_x","gyro_y","gyro_z","temperature"]}
  ]}
}

`sensors/read`

json

{"jsonrpc":"2.0","method":"sensors/read","id":2,"params":{"sensorId":"bme280_0x76"}}

json

{
  "jsonrpc":"2.0","id":2,
  "result":{"readings":[
    {"sensorId":"bme280_0x76","parameter":"temperature","value":22.4,"unit":"°C","timestamp":1234567890,"valid":true},
    {"sensorId":"bme280_0x76","parameter":"humidity","value":58.1,"unit":"%RH","timestamp":1234567890,"valid":true},
    {"sensorId":"bme280_0x76","parameter":"pressure","value":101320.0,"unit":"Pa","timestamp":1234567890,"valid":true}
  ]}
}

Bus History

Bus history accumulates CAN frames, NMEA lines, decoded NMEA 2000 messages, and OBD-II records in circular RAM buffers. The buffers are sized from a configurable RAM budget and their configuration is persisted to LittleFS.

Method	Params	Description
`bus/history/read`	`type`, `limit?`	Read accumulated messages from history buffers
`bus/history/config/get`	—	Read current buffer sizing configuration
`bus/history/config/set`	config fields	Resize buffers and persist configuration

`bus/history/read`

type must be one of: can, nmea, nmea2000, obdii. limit defaults to all stored entries.

json

{"jsonrpc":"2.0","method":"bus/history/read","id":3,"params":{"type":"can","limit":10}}

json

{
  "jsonrpc":"2.0","id":3,
  "result":{
    "type":"can",
    "frames":["7E8#0441050300000000","7E8#04410D0000000000"],
    "count":2,
    "capacity":500
  }
}

json

{"jsonrpc":"2.0","method":"bus/history/read","id":4,"params":{"type":"nmea2000"}}

json

{
  "jsonrpc":"2.0","id":4,
  "result":{
    "type":"nmea2000",
    "messages":[
      {"pgn":129025,"priority":2,"source":0,"name":"Position Rapid Update",
       "valid":true,"hasPosition":true,"latitude":47.6097,"longitude":-122.3331}
    ],
    "count":1,"capacity":200
  }
}

json

{"jsonrpc":"2.0","method":"bus/history/read","id":5,"params":{"type":"obdii"}}

json

{
  "jsonrpc":"2.0","id":5,
  "result":{
    "type":"obdii",
    "records":[
      {"service":1,"pid":12,"name":"Engine RPM","value":1500,"unit":"rpm","valid":true},
      {"service":1,"pid":13,"name":"Vehicle Speed","value":65,"unit":"km/h","valid":true}
    ],
    "count":2,"capacity":300
  }
}

`bus/history/config/get`

json

{"jsonrpc":"2.0","method":"bus/history/config/get","id":6}

json

{
  "jsonrpc":"2.0","id":6,
  "result":{
    "canFrameCount":500,
    "nmeaLineCount":1000,
    "nmea2000Count":200,
    "obdiiCount":300,
    "ramBudgetBytes":1048576,
    "safetyMarginBytes":65536,
    "freeHeapBytes":2097152
  }
}

`bus/history/config/set`

All fields are optional; omitted fields retain their current values.

json

{
  "jsonrpc":"2.0","method":"bus/history/config/set","id":7,
  "params":{"canFrameCount":1000,"ramBudgetBytes":2097152}
}

json

{"jsonrpc":"2.0","id":7,"result":{"ok":true,"canFrameCount":1000,"nmeaLineCount":1000,"nmea2000Count":200,"obdiiCount":300,"ramBudgetBytes":2097152,"safetyMarginBytes":65536}}

Set canFrameCount, nmeaLineCount, nmea2000Count, obdiiCount all to 0 to enable auto-sizing: the server splits ramBudgetBytes equally among the four buffer types based on the size of each record type.

Metrics

Method	Params	Description
`metrics/list`	`category?`	List all registered metrics (name, type, unit, category)
`metrics/get`	`name`	Current value of one metric
`metrics/history`	`name`, `seconds?`	Historical samples for one metric (default: last 300 s)

`metrics/list`

json

{"jsonrpc":"2.0","method":"metrics/list","id":8,"params":{"category":"system"}}

json

{
  "jsonrpc":"2.0","id":8,
  "result":{"metrics":[
    {"name":"system.heap.free","type":"gauge","description":"Free heap","unit":"bytes","category":"system"},
    {"name":"system.uptime","type":"counter","description":"Uptime","unit":"s","category":"system"},
    {"name":"system.wifi.rssi","type":"gauge","description":"WiFi signal strength","unit":"dBm","category":"system"}
  ]}
}

Metric types: counter (cumulative integer), gauge (current value), histogram (min/max/mean/count object).

`metrics/get`

json

{"jsonrpc":"2.0","method":"metrics/get","id":9,"params":{"name":"system.heap.free"}}

json

{
  "jsonrpc":"2.0","id":9,
  "result":{"name":"system.heap.free","type":"gauge","value":214032,"unit":"bytes","category":"system","timestamp":1234567890}
}

For histogram metrics, value is an object: {"mean":…,"min":…,"max":…,"count":…}.

`metrics/history`

json

{"jsonrpc":"2.0","method":"metrics/history","id":10,"params":{"name":"system.heap.free","seconds":60}}

json

{
  "jsonrpc":"2.0","id":10,
  "result":{"name":"system.heap.free","entries":[
    {"ts":1234567800,"val":214100},
    {"ts":1234567830,"val":214032}
  ]}
}

Logs

Method	Params	Description
`logs/query`	`name?`, `seconds?`	Query binary metric log (default: last 3600 s)
`logs/clear`	—	Delete all log entries from LittleFS

json

{"jsonrpc":"2.0","method":"logs/query","id":11,"params":{"name":"system.heap.free","seconds":120}}

json

{
  "jsonrpc":"2.0","id":11,
  "result":{"name":"system.heap.free","count":4,"entries":[
    {"ts":1234567810,"val":214100},
    {"ts":1234567840,"val":214032}
  ]}
}

json

{"jsonrpc":"2.0","method":"logs/clear","id":12}

json

{"jsonrpc":"2.0","id":12,"result":{"ok":true}}

Subscriptions

json

{"jsonrpc":"2.0","method":"resources/subscribe","id":13,"params":{"uri":"sensor://i2c/bme280_0x76"}}

After subscribing the server pushes unsolicited notifications/resources/updated on every value change:

json

{"jsonrpc":"2.0","method":"notifications/resources/updated","params":{"uri":"sensor://i2c/bme280_0x76"}}

TypeScript client example

See [examples/client/client.ts](examples/client/client.ts) for a complete typed client.

---

I2C Sensor Reference

Sensor	Addresses	Parameters	Units
BME280 / BMP280	0x76, 0x77	`temperature`, `pressure`, `humidity`¹	°C, Pa, %RH
MPU6050	0x68, 0x69	`accel_x/y/z`, `gyro_x/y/z`, `temperature`	g, °/s, °C
ADS1115	0x48–0x4B	`ch0_V`, `ch1_V`, `ch2_V`, `ch3_V`	V (±4.096 range)
SHT31	0x44, 0x45	`temperature`, `humidity`	°C, %RH
BH1750	0x23, 0x5C	`light_lux`	lux
INA219	0x40–0x4F	`bus_voltage_V`, `shunt_mV`, `current_mA`, `power_mW`	V, mV, mA, mW

¹ humidity is not available on BMP280.

---

NMEA 0183 Sentences Supported

Sentence	Description	Fields Decoded
GGA	GPS Fix Data	time, lat, lon, fix quality, satellites, HDOP, altitude, geoid separation
RMC	Recommended Minimum Navigation	time, active, lat, lon, speed (kn & km/h), course, magnetic variation
VTG	Track Made Good / Ground Speed	course (true & magnetic), speed (kn & km/h)
GSV	Satellites in View	total satellites, per-satellite PRN, elevation, azimuth, SNR
MWV	Wind Speed and Angle	angle, relative/true, speed, unit (K/M/N)
DBT	Depth Below Transducer	depth (feet / metres / fathoms)
DPT	Depth of Water	depth (metres)
HDG	Heading – Deviation & Variation	heading, deviation, variation (E/W)
HDT	Heading – True	heading (true north)

Parsing features: XOR checksum validation, DDMM.MMMM → signed decimal degrees, HHMMSS.SS time, talker ID extraction, graceful empty-field handling.

---

NMEA 2000 PGNs Supported

PGN	Name	Key Fields
127250	Vessel Heading	`heading`, `variation`
127257	Attitude	`pitch`, `roll`, `yaw`
128259	Speed Through Water	`speedKnots`
128267	Water Depth	`depthMetres`, `offset`
129025	Position Rapid Update	`latitude`, `longitude`
129026	COG & SOG	`courseOverGround`, `speedOverGround`
130306	Wind Data	`speedKnots`, `angle`, apparent/true flag
130310	Water Temperature	`tempCelsius`

---

OBD-II PIDs Supported (Service 01)

Selected PIDs decoded; full list in src/CANParser.cpp:

Category	PIDs
Engine	RPM, load, coolant temp, intake air temp, MAP, MAF, timing advance
Fuel	Fuel pressure, trim (short/long), rail pressure, injection timing, fuel rate
Emissions	O2 sensor voltages, EGR, evap system, DPF pressure
Motion	Vehicle speed, throttle position, accelerator pedal position
Temperature	Oil temp, intake air temp, EGR temp, engine exhaust gas temps (EGT)
Electrical	Control module voltage, battery voltage
Hybrid	Hybrid battery remaining life
Torque	Driver demand, actual torque, reference torque
Vehicle info	VIN, calibration IDs (service 09)

---

Discovery

On network connect the server registers two mDNS services and periodically sends a UDP capability beacon:

Discovery	Details
mDNS	`_mcp._tcp` and `_http._tcp` with TXT records: version, capabilities, detected sensors
UDP broadcast	JSON beacon to `255.255.255.255:5354` every 30 s (configurable); includes sensor manifest

mDNS and UDP are triggered automatically on network join, I2C scan completion, MCP server ready, and bus history config changes.

---

Testing

Tests compile and run natively on Linux — no hardware required.

bash

# All tests
pio test -e native

# Specific suites
pio test -e native -f test_nmea_parser
pio test -e native -f test_can_parser
pio test -e native -f test_i2c_sensors
pio test -e native -f test_bus_reader
pio test -e native -f test_mcp_server
pio test -e native -f test_metrics_system

# With coverage (requires lcov)
pio test -e native --coverage

Suite	What is covered
`test_nmea_parser`	GGA, RMC, VTG, GSV, MWV, DBT, DPT, HDG, HDT, checksum validation
`test_can_parser`	OBD-II PIDs, NMEA 2000 PGNs 127250/127257/128259/128267/129025/129026/130306/130310
`test_i2c_sensors`	BME280, MPU6050, ADS1115, SHT31, BH1750, INA219 via mock I2C
`test_bus_reader`	Timed reads, raw/parsed modes, timeout handling
`test_mcp_server`	JSON-RPC dispatch, resource management, method registration
`test_metrics_system`	Counters, gauges, histograms, LittleFS persistence

---

Extending with Custom MCP Methods

cpp

mcpServer.registerMethodHandler("myns/doSomething",
    [](uint8_t clientId, uint32_t reqId, const JsonObject& params) {
        StaticJsonDocument doc;
        doc["result"]("ok") = true;
        std::string out;
        serializeJson(doc, out);
        return out;
    });

// Remove when no longer needed
mcpServer.unregisterMethodHandler("myns/doSomething");

---

Contributing

1. Fork the repository

2. Create a feature branch: git checkout -b feature/my-feature

3. Add tests for new functionality (pio test -e native must pass)

4. Open a pull request

See CONTRIBUTING.md for coding style and guidelines.

---

License

MIT — see LICENSE.

Esp32mcpserver

Documentation

ESP32 MCP Server

Features

Supported Boards

ESP32 Boards — Full MCP Server (WiFi + WebSocket + CAN)

nRF52840 Boards — Sensor Only (I2C + Serial, no WiFi)

Board Feature Matrix

Architecture

Hardware

Pin Assignments (ESP32-S3-DevKitC-1)

nRF52840-DK Pin Assignments

Bill of Materials

ESP32-S3-DevKitC-1 Wiring

I2C Sensor Wiring

NMEA 0183 Wiring (GPS / Chart Plotter)

CAN Bus Wiring (NMEA 2000 / OBD-II)

Software Prerequisites

Build & Flash

nRF52840

First Run

Web Dashboard

HTTP Endpoints (port 80)

MCP API Reference (WebSocket port 9000)

Protocol

Sensors

sensors/i2c/scan

sensors/read

Bus History

bus/history/read

bus/history/config/get

bus/history/config/set

Metrics

metrics/list

metrics/get

metrics/history

Logs

Subscriptions

TypeScript client example

I2C Sensor Reference

NMEA 0183 Sentences Supported

NMEA 2000 PGNs Supported

OBD-II PIDs Supported (Service 01)

Discovery

Testing

Extending with Custom MCP Methods

Contributing

License

Similar MCP

Mcpmcp Server

Imagen3 Mcp

Mcp Open Library

Metmuseum Mcp

Trending MCP

Playwright Mcp

Serena

Mcp Playwright

Mcp Server Cloudflare

Mcpmcp Server

Imagen3 Mcp

Mcp Open Library

Metmuseum Mcp

Playwright Mcp

Serena

Mcp Playwright

Mcp Server Cloudflare

`sensors/i2c/scan`

`sensors/read`

`bus/history/read`

`bus/history/config/get`

`bus/history/config/set`

`metrics/list`

`metrics/get`

`metrics/history`
